Introduction on BMS Site Engineer Course
Modern-day building facility involves many equipment and systems for the comfort and safety of building users. A Building Management System (BMS) or Building Automation and Control System (BACS) is a system that manages and monitors all building systems, including the Electrical system, HVAC system, Plumping systems, Lighting controls, CCTV and Security systems, Life cycle safety systems, renewable energy production, and electricity and gas meters, etc.
This course on BMS systems design will help BMS site engineers working in BMS industry or Engineers desiring to pursue career in BMS site engineer role to acquire overall knowledge and practical skills on the interconnected BMS systems and the programming and designing of BMS controller.
Course Details
|
Course : |
BMS Site Engineer course (BSE) |
|
Duration: |
30 hours |
|
Language: |
English |
|
Location: |
Dubai, Riyadh, Dammam, Doha |
|
Mode: |
Classroom Instructor-led Training (CILT) and Virtual Instructor-led Training (VILT) |
|
Certificate: |
KHDA |
At the end of this course, participants will learn the following.
- Introduction, role, and Architecture of BMS
- Project documents involved in BMS.
- Overview of various key systems within BMS such as HVAC, MEP, Plumping, etc
- Various communication protocols are used within the BMS network
- DDC controller and different data types used
- DDC Controller programming and logic development
- Supervisory controller programming and graphics development
- Alarm, trends, and troubleshooting of BMS systems
Module -1
- Introduction to BMS
- Benefits of BMS
- Evolution & Future of BMS
- General BMS Architecture
- Layers of arrangement
- How Does It works
- Roles in BMS system (Hierarchy)
Module -2
- BMS General documents
- Data point list
- Shop Drawing
- As built Drawing
- Control schematic
- Wiring drawing
- Sequence of Operation
- Work inspection request
- O&M manual
- Product Datasheet
Module -3
- Basics of MEP Equipment
- Details HVAC Equipment
- Details of Controllers & Gateways
- Details of Field Devices
- Third party Devices
- DDC panel overview
- Control Cables overview
Module -4
- Communication protocols - Introduction
- Networking Basics
- BMS Networking.
- MS/TP or TCP/IP
- Lon Protocol
- BACnet Protocol and its integration
- Modbus Protocol and integration
- M-Bus Protocol and Integration
- Other common protocols
- MAC Address concept of controller
Module -5
- Types of Data used in BMS
- Designing of Project
- Selection of product
- Design of DPS
- Concept of Workstation
- Requirement of workstation
- Portable Operator Terminal (POT)
- Server Overview
- Redundancy server or system
Module -6
- Engineering Tools?
- Software Installation
- Data Base
- Software & Supervisory License
- Tools needed for commissioning
- Project creation
- IO point & Objects configurations
- Programming
- Control logic creations.
- Sample logics for Equipment
- Upload/Download from controller
Module -7
- BMS graphics
- Page creation
- Creation of Equipment
- Points Mapping & Binding
- Animations for equipment
- Alarms
- Schedules
- Trend logs
Module -8
Practical session on the following
- Field devices
- DDC programming
- Workstation
- Graphics development
- Alarms, Trends, Schedules
- Troubleshooting
