This course is designed to give you a deep understanding of how a VFD works in an Industrial environment, the configuration of parameters, control philosophies, VFD selection criteria, and On-site troubleshooting concepts.
Objectives:
- Upon completing the VFD course from IIPD, the candidate should be able to perform the following functions at the site,
- Locating and identifying the hardware system
- Selection of VFD as per motor capacity
- Do basic troubleshooting
- Configure Motor parameter
- Set up VFD for working with PLC or other hardware
- Wiring the Digital & Analog I/O's
Outline:
- Design of the System and Components
- Electrical Basics Review
- Different motor-starting methods
- Incoming Power (line) Wiring
- Motor (load) Wiring
- Control Wiring
- Keypad Controls
- Terminal Strip Control - Automatic, Manual
- Bus Communication Control
- IP setting and communication on the Profinet Network
- Open Loop Control
- Manual Operation, Connection Macros
- Automatic Operation - 2/3 wire mode
- References & Limits
- Motor Speeds - Min, Max, and Preset
- Ramp Times
- Speed Reference
- Inputs / Outputs Functions - Analog, Digital, and Relay
- Configuring using TIA Portal for Profibus/Profinet Network
Pre-Requisite:
- Understanding of Electrical Systems, Motors & Installations
- Programming Experience in Siemens TIA Portal
- Basic Knowledge of Automation Systems
- Engr/Technician Level candidates
Methodology:
- One to One - Hands-on sessions
- On-Line Sessions (Batch)
